Double-rail gantry crane
P300
Product highlights
- Ideally suited for subsequent installation in small halls without crane system
- Small footprint
- Static load of hall is not affected
- Compact design, perfectly suited for small rooms
- Large effective lifting height
- Support height and crane rail length / width can be adjusted to conditions on the spot
- Outdoor use possible
- Optional electric trolley enables comfortable and smooth crane operation
- Easy to install thanks to dowelling on concrete floor (optional)
The double-rail gantry
The double-rail gantry crane P300 is the perfect choice when any point in a room needs to be approached.
Using the gantry crane P300, you are able to lift maximum loads of 2,000 kg effortlessly and cover the entire workspace. The two-rail gantry is ideally suited for subsequent installation in small halls without crane system. The static load of the hall structure is not affected because the crane stands on its own four feet and no additional costs for bracing are incurred.
Due to its compact design, the hall crane P300 features a maximum lifting height and is perfectly suitable for small and narrow operating rooms. With the optional electric trolley for the overhead crane, the two-rail gantry offers more ease of use when handling higher capacities. The two-rail gantry P300 perfectly meets your requirements for indoor and outdoor use since its support height and crane rail length / width can be adjusted individually.
Regarding fastening options, you can make your individual choice from comfortable doweling on concrete floor or fastening on foundation using anchors.
Moreover, we offer a suitable power supply, electric chain hoists ELECTROLIFT® with electric trolley, radio remote control, as well as various other accessories.
This type of crane is also available with variable maximum crane rail length (gantry crane P400).
Technical data
Capacity: | 500 - 2000 kg |
Width: | 3000 - 6000 mm |
Length: | 2000 - 10 000 mm |
Jib clearance: | 2500 - 6000 mm |
Total height: | 3100 - 6550 mm |
EN 15011 Hoisting class: | HC2 |
EN 15011 Stability class: | S2 |
Crane drive: | By Hand / Electrical |
Hoist: | Chain hoist |
Trolley drive: | By hand / Electrical |
Installation location: | Indoor / Outdoor |
Length [m]
Capacity [kg]
2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | |
---|---|---|---|---|---|---|---|---|---|
500 | |||||||||
800 | |||||||||
1000 | |||||||||
1600 | |||||||||
2000 |
